I wrote my own guitar effects with AI, and learned DSP by accident

I play guitar, badly but happily, and I’ve always treated pedals as magic boxes: turn the knob, the sound changes, don’t ask. This summer I asked. I wanted to build my own effects in code and hear them in real time, with Claude as a patient tutor and co-author. This is what I learned, starting from basically zero audio knowledge.

First, the sounds

Here’s the same riff through four chains I built. The input is a synthetic plucked string (Karplus–Strong, more on that below), so what you’re hearing is only the effects, not my playing.

Dry0:00

Glassy clean0:00

Plexi crunch0:00

Comfortably wet0:00

Lesson 1: audio is just arrays, very fast

Digital audio is a list of numbers between −1 and 1, one every 1/48000th of a second at 48 kHz. A real-time effect gets that list in small chunks called buffers, transforms them, and has to hand them back before the next one arrives.

The buffer size is a trade-off you can feel with your fingers. At 256 samples and 48 kHz each buffer is 5.3 ms of audio. Smaller buffers mean less delay between picking a string and hearing it, but less time to do the work and a higher risk of clicks when you run out of it. I ended up at 256, which is responsive enough to play through.

My engine runs its own loop, reading from the interface, processing and writing out, instead of using the library’s built-in duplex stream. That costs one extra buffer of latency, but it means I can meter the levels and keep a ring buffer of the last few seconds of output, which becomes important later.

while not self._stop.is_set():
    chunk = inp.read(self.buffer_size)
    with self._lock:
        board = self._chain.board
    processed = board(chunk, self.sample_rate, reset=False)
    self._meter(chunk, processed)
    self._push_capture(processed)
    out.write(processed.astype(np.float32, copy=False), self.sample_rate)

reset=False is the important bit. Filters, delays and reverbs have memory: their output depends on previous samples. Reset them between buffers and you hear a click every 5 ms.

Lesson 2: an overdrive is a filter sandwich

I asked Claude to explain what’s actually inside a Tube Screamer, the most copied overdrive ever. The answer changed how I think about all distortion: clipping is only the middle of it. The filters around it do most of the work.

1. A mid boost around 720 Hz before the clipping, so the mids break up first. That’s the famous “mid hump” that helps a guitar cut through a band.
2. A high-pass to cut the lows before clipping, because distorted bass turns to mud.
3. Soft clipping: the waveform’s peaks get rounded off instead of chopped, which adds warm harmonics.
4. A low-pass after clipping. That’s the tone knob, taming the fizzy harmonics clipping creates.
5. Output level, compensated so turning up drive doesn’t just make it louder.

In code, that recipe is one function that maps three knobs to five processing stages:

def _od(r: dict[str, float]) -> list[dict[str, float]]:
    # Tube Screamer topology: mid hump in, soft clip, tone lowpass, level out.
    return [
        dict(cutoff_frequency_hz=720.0, gain_db=3.0 + 3.0 * (r["drive"] / 30.0), q=0.8),
        dict(cutoff_frequency_hz=110.0),
        dict(drive_db=r["drive"]),
        dict(cutoff_frequency_hz=r["tone"]),
        dict(gain_db=r["level"] - r["drive"] * 0.55),
    ]

The same function builds the effect and updates it live when a knob moves, so the two can never drift apart. Moving a knob just sets new values on the existing filters. Only adding or removing a whole block rebuilds the chain, and that swap happens at a buffer boundary so you never hear it.

Lesson 3: knobs are logarithmic because ears are

My first tone knob felt broken: nothing happened for most of the range, then everything happened at once. Our hearing is logarithmic. Going from 1 kHz to 2 kHz sounds like the same step as 4 kHz to 8 kHz. So any knob that controls a frequency or a time needs a log curve:

def denorm(self, value: float) -> float:
    value = min(1.0, max(0.0, value))
    if self.curve == "log":
        return self.lo * (self.hi / self.lo) ** value
    return self.lo + (self.hi - self.lo) * value

Every knob is stored as 0–1 and converted to real units (Hz, dB, ms) through its own curve. That also turned out to be a great interface for an AI, which I’ll get to in a later post.

Lesson 4: the cabinet is the secret

My first amp simulation sounded like an angry bee. The reason: a real guitar speaker in a cabinet is a steep low-pass filter, and almost nothing above ~5 kHz makes it out. Without that filter, all the harsh upper harmonics from clipping go straight to your ears. Adding a simple cab block (a low cut, a body resonance and a high cut around 5 kHz) did more for realism than any amount of tweaking the amp.

Lesson 5: a plucked string in four lines

To make test audio without plugging in a guitar, Claude pointed me to Karplus–Strong, which is honestly beautiful. Fill a buffer one period long with noise, then keep averaging neighbouring samples as you loop around it. The averaging is a gentle low-pass, so the tone gets purer and quieter over time, exactly like a real plucked string.

buf = rng.uniform(-1, 1, int(SR / freq))
for i in range(n):
    out[i] = buf[i % len(buf)]
    buf[i % len(buf)] = 0.996 * 0.5 * (buf[i % len(buf)] + buf[(i + 1) % len(buf)])

That riff at the top is made this way. It’s also what got me thinking about generating music, not just processing it. That’s coming in a later post.

How working with Claude went

I built on top of Spotify’s pedalboard library for the low-level DSP (filters, clippers, delays, reverb) and put my effort into the design: what goes in each block, in what order, with which knobs. Claude was most valuable as a tutor with infinite patience. I asked “why” constantly: why does this sound muddy, why does order matter, what is Q. The answers came with the maths when I wanted it and without it when I didn’t.

The best habit I picked up: render and measure, don’t guess. When something sounded wrong, I’d have the agent run a test signal through the chain and print the spectrum. Knowing where the energy actually was took much of the guesswork out of fixing it.
